Stationery Sheet Extrusion
Features:
- 1. The stationery sheet extrusion machine uses motor to direct connection with retarder to improve transmission rate.
- 2. This PP stationery sheet extrusion line adopts horizontal structure, roller direct connection transmission, line speed and traction line speed by synchronic control.
- 3. Roller temperature is controlled independently and the double convection system for roller cooling which will provide very high heat exchanged rate and to keep the even roller surface temperature.
- 4. Roller utilizes pressure-type installation, so that it can easy to change roller with whole veins.
- 5. The stationery sheet extrusion machine is equipped with a computer presetting length slitter to achieve the online cutting.
- 6. Our PP stationery sheet extrusion line adopts PLC control system to automatically control the parameter setting, data computing and back, alarm and so on.
Specifications
| Model No. | WJP90-1000 | WJP90-1300 |
| Suitable materials | PP/PE | PP/PE |
| Screw size | Φ90×34 | Φ90×34 |
| Roller size | Φ316×1000 | Φ316×1300 |
| Sheet thickness | 0.05-0.2mm | 0.25-1.8mm |
| Sheet width | ≤700mm | ≤1050mm |
| Max throughput | 150-180kg/h | 150-200kg/h |
| Total capacity | 175kw | 185kw |
